HGH15-65 Square Linear Guide Slider for CNC & Automation

Product Overview

The HGH15-65 Square Linear Guide Slider offers precise linear motion for various applications such as CNC machines, automation systems, and 3D printers. It features high rigidity, smooth movement, and exceptional load capacity. Designed for durability, it ensures long-lasting performance in demanding environments, making it ideal for high-precision tasks. This guide slider is easy to install and maintain, providing efficient, reliable motion for a wide range of industrial uses.

Product Benefits

• Smooth Motion with Four-Row Groove Design
  The HGH15-65 features a four-row circular-arc groove design that increases ball-to-track contact, reducing friction and ensuring highly stable, smooth linear motion. This allows for precise operation even at high speeds or under heavy loads, making it ideal for CNC equipment, automation systems, and high-precision machinery.

• Consistent Performance in All Directions
  Designed with equal load ratings across radial, reverse radial, and lateral directions, this guide slider maintains balanced performance regardless of motion direction. It offers greater design flexibility and ensures structural stability, especially in multi-axis systems or robotic applications.

• Built-In Self-Aligning Capability
  The self-aligning function compensates for slight misalignments during installation, reducing the chance of premature wear and extending the system’s service life. It simplifies the mounting process and minimizes the need for constant adjustments, improving productivity and long-term reliability.

• High Rigidity and Long-Term Durability
  Constructed with a high-rigidity structure and wear-resistant materials, the HGH15-65 withstands high loads and harsh operating conditions without deformation. Its robust design leads to reduced maintenance frequency and offers a reliable, cost-effective solution for continuous industrial use.

Applications

• Precision and Rigidity for CNC & Automation

The HGH15-65CA square linear guide slider is engineered for high rigidity, stability, and precision in automation-intensive environments. Whether used in CNC machinery, robotic arms, or industrial 3D printers, it provides the consistent linear motion essential for long-term accuracy and structural endurance.

Ideal for CNC machines & high-load automation equipment

• Robust Dimensions for Stable Mounting

With an overall length of 200.2 mm and slider width of 60 mm, the HGH15-65CA ensures wide surface contact for smooth travel. A bolt hole pitch (K) of 43.1 mm and M12×20 mounting holes support easy, secure integration into standard systems.

Suitable for robotic systems requiring precise and stable alignment

• High Load Capacity for Demanding Tasks

Offering a dynamic load rating of 163.63 kN and static load rating of 215.35 kN, this slider excels in carrying both operational and resting loads. Its moment resistance (6.65 / 4.27 / 7.00 kN·m) ensures exceptional stability under torque from multiple directions.

Perfect for multi-axis milling machines and industrial actuators

• Stiff Yet Lightweight for Motion Efficiency

Despite its strength, the HGH15-65CA weighs just 7.00 kg, striking a balance between mass and mechanical performance. This makes it efficient for dynamic applications without sacrificing rigidity.

Fits well in medical equipment or precision control systems

• Smooth Motion with Advanced Groove Design

The signature four-row circular-arc groove reduces friction and vibration, ensuring ultra-smooth motion. This makes it ideal for high-speed processes where repeatability and precision are paramount.

Optimized for 3D printers, aerospace tools, and critical automation

HGH15CA - HGH65CA
